iHF High Quality Aluminum Alloy Stainless Steel Motor Shaft Couplings
Productfeatures:
This aluminum alloy diaphragm coupling features a high-strength aluminum body and a stainless steel core diaphragm, combining lightweight design with durability. It offers exceptional torsional rigidity and ultra-low inertia for precise shaft control and high-speed responsiveness, with symmetrical performance in both rotational directions. Ideal for high-precision applications such as robotics, optical instruments, and semiconductor equipment, its wear-resistant design ensures long-term stability and significantly reduces maintenance costs. This coupling is a reliable, high-performance solution for improving efficiency and longevity in demanding power transmission systems.
Coupling:
| Model Number | QLFCAW QSECAW QLFCAN QSECAN |
| Product Type | Single/Double Diaphragm Coupling |
| Body Material | Aluminum Alloy |
| Key Component Material | Stainless Steel Discs |
| Surface Treatment | Anodized/Pearl Nickel Plating |
| Trademark | iHF |
| HS Code | 8483600090 |
| Quality Certification | ISO 9001,RoHS |
| Standard Packaging | Individual PE Bag+Standard Export Carton |
| Feature | High Rigidity/High Torque Capacity/Low Inertia |
| Application | Medical Imaging Diagnostic Equipment/Screen Printing Machines/CT Scanners/Food Processing Machinery |
| Specification | Standard |
| Origin | Dongguan(Mainland) |
| Production Capacity | 500000 PCS/Year |
Product Description:
| Product Type | High-Sensitivity Single/Double Diaphragm Coupling |
| Body Material | Aluminum Alloy |
| Key Component Material | Stainless Steel |
| Surface Treatment | Anodized/Pearl Nickel Plating |
| Operating Temperature Range | -30℃~100℃ |
| Bore Connection Type | Clamp Type |
| Misalignment Compensation Types | Angular&Axial |
| Permissible Misalignment | ±0.1~±0.6mm |
| Backlash | Zero Backlash |
| Standard Bore Diameter Range | 3 4 4.5 5 6 6.35 7 8 9 9.5 10 11 12 12.7 14 15 16 17 18 19 20 22 24 |
| Outer Diameter | 16 20 25 32 40 50 |
| Overall Length(Single Diaphragm) | 16.5 18.4 21.6 29 35 41 |
| Overall Length(Double Diaphragm) | 23.2 26 30.2 41 47 53 |
| Mounting Screw | Hexagon Socket Head Cap Screw |
| Quality Certification | ISO 9001:2015,IATF 16949:2016,RoHS |
| Application Industry | Machine Tools, Metallurgy and Mining Industries, Chemical and Petroleum Machinery, Aviation & Aerospace and Marine, Power Generation Units |
Application
High quality aluminum alloy stainless steel motor shaft couplings are a proven solution for modern mechanical systems, combining lightweight efficiency with heavy-duty performance. Their durability, corrosion resistance, and precision engineering make them indispensable in industries that demand reliable and long-lasting power transmission components.
For companies seeking to improve efficiency, reliability, and machine longevity, choosing aluminum alloy and stainless steel shaft couplings is an investment that delivers measurable benefits.
