Hollow Rotary Actuator High Accuracy Hollow Rotating Platform Rotary Positioners PTN060

Product features:

The PTN060 is a cost-effective model within our Hollow Rotary Table series, designed for medium-to-low torque automation applications. It is compatible with NEMA 17 stepper motors and 50W/100W AC servo motors, offering gear ratios of 5:1 or 10:1. It features a backlash of ≤1 arc-min and repeatability of ±15 arc-sec, ensuring precise indexing and positioning. Inheriting the platform's core advantages, it includes a through-hole design and high-rigidity cross roller bearings for easy cabling and robust performance. With a standard IP40 protection rating, it is suitable for common industrial environments. Furthermore, it can be seamlessly combined with our PX42 planetary gearboxes to expand the available speed and torque ranges, providing a compact and efficient rotary solution for your equipment.
