Request Quote iHF Precision Engineered High-Speed Stainless Steel Spur Gear for Machinery
Productfeatures:
Type A Spur Gear is designed with a standard 20°pressure angle and a fine 0.5 module, ensuring smooth engagement and efficient power transmission. Available in a wide range of tooth counts (20 to 120), it offers flexibility in speed and torque ratio design. Each gear is precision-manufactured with a round bore and complies with the GB/T 10095-2008 Grade 8 accuracy standard, providing reliable performance with minimal noise and vibration.
Ideal for light to medium-duty applications, this gear is commonly used in precision automation equipment, small conveyor systems, printing machinery, packaging units, and office automation devices where space constraints, quiet operation, and dependable motion control are essential.
| Product Name | Type A Spur Gear |
| Material | SUS303/S45C/Brass |
| Product Model | ZC8SE ZC8SF ZC8SN ZC8CU ZC8SU ZCG8SF |
| Tooth Profile | A |
| Transport Package | Cartons |
| Trademark | iHF |
| HS Code | 8483900090 |
| Manufacturing Process | Casting |
| Surface Treatment | Blackening/Electroless Nickel Plating |
| Surface Color | Clear/Black/Silver |
| Application | Printing/Laser Equipment/Automated Production Lines/Woodworking Machinery/Packaging Equipment/ Logistics and Storage Machinery/ Robotics/Machine Tool Equipment |
| Specification | Standard |
| Origin | Dongguan(Mainland) |
| Production Capacity | 500000 PCS/Year |
| Product | Standard Spur Gear |
| Customized | OEM, Drawings or Samples Customized |
| Tooth Profile | Type A |
| Module | 0.5 |
| Pressure Angle | 20° |
| Surface Treatment | Blackening/Electroless Nickel Plating |
| Material | S45C(45# steel);SUS304(stainless steel);Brass |
| Bore | Round Bore |
| Heat Treatment | Tooth High-Frequency Hardening |
| Standard | DIN, ISO/GB, AGMA, JIS |
| Teeth Accuracy | DIN, ISO/GB Class 4, AGMA Class 13, JIS Class 0 |
| Weight | Max 15 Tons |
| Testing Equipment | Projecting apparatus, salt spray test, durometer, and coating thickness tester, 2D projector |
| Producing Equipment | CNC machine, automatic lathe macine, stamping machine, CNC milling machine,rolling maching, lasering, tag grinding machine etc. |
| Machining Process | Gear Hobbing, Gear Milling, Gear shaping, Gear Broaching, Gear Shaving, Gear Grinding and Gear Lapping |
| Application Industry | Robot industry, Medical industry, Making machine industry, Automation industry, 3C industry equipment, Packaging industry, UAV industry, New energy industry |
-
*
-
*
-
*
-
-
