Request Quote iHF Low Noise High Precision Miniature Ball Linear Guide for Semiconductor Equipment
Productfeatures:
Engineered for space-constrained, high-precision equipment, the DGMN Series offers flexible configuration and reliable performance for applications from micro-automation to large inspection systems.
Key Advantages
· Flexible Configuration: Rails are customizable from 25mm to 2000mm, supporting 1 to 8 blocks per rail to optimize for travel and load needs.
· Dual Material Options: Choose corrosion-resistant Stainless Steel for medical or cleanroom use, or high-rigidity Carbon Steel for demanding industrial applications.
· Two Accuracy Grades: Select Standard Grade for cost-effective automation, or Precision Grade for semiconductor, laser processing, and measurement fields.
This series is an ideal linear motion solution for semiconductor equipment, medical instruments, robotics, and optical platforms.
Please note: Specifications are subject to the official technical manual.
| Product Name | Linear Guides |
| Product Series | Miniature |
| Product Model | DGMN |
| Precision Grade | C/H/P |
| Transport Package | Cartons |
| Trademark | iHF |
| HS Code | 8466939000 |
| Material | Carbon Steel,Stainless Steel |
| Standard Length | 25-2000mm |
| Surface Treatment | Anodic Oxidation |
| Application | Semiconductor&Electronics Manufacturing/Medical & Laboratory Automation/High-End Machine Tools & Precision Machining/Advanced Robotics & Factory Automation |
| Specification | Standard |
| Origin | Dongguan(Mainland) |
| Production Capacity | 100000 PCS/Year |
| Product Name | Miniature Linear Guides |
| Customized | OEM, Drawings or Samples Customized |
| Product Model | DGMN-C/DGMN-H |
| Slider Type | Flanged Slider |
| Number of Slider | 1~8 |
| Rail Length | 25-2000mm |
| Rated Load | Dynamic:0.38-6.37 Static:0.54-9.11 |
| Accuracy Grade | Standard(C)/Advanced(H)/Precision(P) |
| Material | Carbon Steel,Stainless Steel |
| Surface Treatment | Anodic Oxidation |
| Surface Color | Natural/Clear |
| Preload Grade | Standard(ZF/Z0),Customized(ZI) |
| Weight | Max 15 Tons |
| Qualifications & Certifications | ISO 9001, ITAF, RoHS |
| Packaging & Delivery | Anti-rust oil/bag+Hard Case Standard Product: 5 working days Customized Product: 7-10 working days |
| Application Industry | Robot industry, Medical industry, Making machine industry, Automation industry, 3C industry equipment, Semiconductor industry, New energy industry |
-
*
-
*
-
*
-
-
