Small Internal Spur Pinion Plastic Forged IHF
Productfeatures:
Unlike conventional machined gears, the plastic forged structure provides optimized material density and improved wear resistance while significantly reducing overall weight. This makes it particularly suitable for lightweight mechanical assemblies where efficiency and smooth engagement are critical.
The internal spur tooth design ensures precise meshing with mating gears, enabling efficient power transmission in confined spaces. It is widely used in automation equipment, precision instruments, small gearboxes, medical devices, office machinery, and other micro-mechanical drive systems.
Key advantages include:
High precision internal tooth geometry for smooth engagement
Lightweight plastic forged structure with strong mechanical strength
Low noise and vibration during operation
Excellent wear resistance and long service life
Suitable for OEM/ODM customization based on technical requirements
Precision Gear:
| Product Name | helical gear/spur gear |
| Material | Plastic |
| shape | Pinion |
| warranty | 1.5 year |
| machinery test report | Provided |
| Trademark | iHF |
| place of origin | Guangdong, China |
| pressure angle | 20 |
| Material Standard | PA66, POM, PEEK, Nylon, Delrin,etc |
| Heat Treatment | Quenching & Tempering, Carburizing & Quenching |
| Bore | Finished bore, Pilot Bore, Special request |
| Hardness | 55- 60HRC |
| Size | Customer Drawings & ISO standard |
| Gross weight per batch | 2.000 kg |
Product Description:
| Product Name | helical gear/spur gear |
| Material Standard | Stainless Steel, Carbon Steel, Brass, Bronze, Iron, Aluminum Alloy etc |
| Heat Treatment | Quenching & Tempering, Carburizing & Quenching, High-frequency Hardening, Carbonitriding...... |
| Bore | Finished bore, Pilot Bore, Special request |
| Hardness | 55- 60HRC |
| Size | Customer Drawings & ISO standard |
| Certificate | ISO9001:2008 |
| Teeth Number | 10-100 |
| Surface Treatment | Carburizing and Quenching |
| Precision Grade | DIN5 TO DIN7 |
| Machining process | Gear Hobbing, Gear Milling, Gear Shaping, Gear Broaching, Gear Shaving, Gear Grinding and Gear Lapping |
| Processing Method | Molding, Shaving, Hobbing, Drilling, Tapping, Reaming, Manual Chamfering, Grinding etc |
| Package | Wooden Case/Container and pallet, or made-to-order |
| Apllications | Electric machinery, metallurgical machinery, environmental protection machinery, electronic and electrical appliances, road construction machinery, chemical machinery, food machinery, light industrial machinery, mining machinery, transportation machinery, construction machinery, building materials machinery, cement machinery, rubber machinery, water conservancy machinery and petroleum machinery |
Application
The Small Internal Spur Pinion Plastic Forged IHF is a high-performance, compact internal spur pinion widely utilized in various mechanical transmission systems. Thanks to its fabrication via a plastic forging process, it features a lightweight design, excellent wear resistance, and superior corrosion resistance, making it ideally suited for applications in household appliances, toys, automation equipment, robotics, and similar fields.
