Position: Home > Product Center > iHF > Linear bearings > iHF Linear Bearing Housing Units for Transportation Device

iHF Linear Bearing Housing Units for Transportation Device

Productfeatures:

iHF housing units ensure high precision and stable operation for transportation systems through robust design and strict manufacturing tolerances. They feature low-friction operation and enhanced load capacity for heavy-duty applications. The design enables easy installation and maintenance, with protective seals against contamination. Available in versatile configurations like pillow block and flange mounts, they offer a reliable solution for improved productivity and longer service life in industrial equipment.


iHF Linear Bearing Housing Units for Transportation Device
iHF Linear Bearing Housing Units for Transportation Device
iHF Linear Bearing Housing Units for Transportation Device
iHF Linear Bearing Housing Units for Transportation Device
iHF Linear Bearing Housing Units for Transportation Device
iHF Linear Bearing Housing Units for Transportation Device
iHF Linear Bearing Housing Units for Transportation Device
Get a free quote
Linear bearings:
Product NameLinear Bearing Housing Units
Model CodeZF20KW/ZF20LW
Cage MaterialAluminium Alloy
Structure TypeLong/Extra-Long
Transport PackageCartons
TrademarkiHF
HS Code8483200000


Precision GradeNormal Grade
Surface TreatmentNatural Anodized
Surface ColorNatural
ApplicationLight-Duty Automation & Factory Automation/Machine Tools & Metalworking/Semiconductor & Electronics Manufacturing
SpecificationStandard
OriginDongguan(Mainland)
Production Capacity100000 PCS/Year
Product Description:
ProductLong/Extra-Long Linear Bearing Housing Units
Main TypesSingle/Double Bushing, Standard, Compact
Bore Diameter10 12 16 20 25 30
Outer Diameter40 42 50 54 76 78
Length93 96 100 115 118 134 160 170 185 200
Surface TreatmentNatural color anodizing
Operating Temperature－15℃~80℃
Protection LevelIP54
LubricationPre-lubricated with long-life grease. Equipped with grease nipple for re-lubrication
Sealing MethodRubber Contact Seals at Both Ends
Unit Weight240~1955g
Key FeaturesReady-to-Use, High Rigidity, Easy Mounting, Effective Sealing,System Compatibility
Core Selection ParametersShaft Diameter, Mounting Type&Dimensions, Load Ratings, Precision Grade
Application IndustryFactory Automation Equipment, 3D Printers&Engraving Machines, Medical & Inspection Equipment, Packaging & Material Handling Systems


iHF Linear Bearing Housing Units for Transportation Device
Application
From enabling the precise layers of a 3D print to ensuring the reliable operation of an automated production line, linear bearings provide a critical and economical solution for converting rotary motion into controlled linear movement, offering an optimal balance of performance, durability, and cost for countless engineering applications.
