iHF Cross Roller Slide for 3C Inspection Equipment
Productfeatures:
The cross-roller slide employs a structure with rollers arranged crosswise on two V-groove guides. The rollers move and guide along the V-grooves, significantly improving motion accuracy and stability.
Our product range mainly includes: Micrometer Head Feed, Lead Screw Driven, and Micrometer Head Driven. Multiple axial configurations are available, including X-axis, Y-axis, XZ-axis, and XYZ-axis.
· Micrometer Head Feed: Offers quantitative adjustment with a minimum reading of 0.01mm, making it suitable for applications requiring precise adjustments.
· Lead Screw Driven: Designed for fine feed applications. As it lacks a scale, it is not suitable for numerically controlled operations.
· Micrometer Head Driven: Provides a resolution of up to 0.5μm, enabling finer adjustments than standard micrometer knob types.
These product types meet various precision positioning and adjustment requirements across different applications demanding high accuracy and control.
Precision Positioning Stage:
| Product Model | Manual X-Axis Stage |
| Material | Aluminum Alloy |
| Module | ZD41AB |
| Motion Direction | X-axis |
| Transport Package | Cartons |
| Trademark | iHF |
| HS Code | 9031900090 |
| Feed Type | Micrometer Head Feed |
| Surface Treatment | Black Anodized |
| Surface Color | Clear/Black/Natural |
| Application | Precision Electronics, Precision Optics, Laser Processing, Lithium-ion Battery Manufacturing, Optoelectronics |
| Specification | Standard |
| Origin | Dongguan(Mainland) |
| Production Capacity | 100000 PCS/Year |
Product Description:
| Product | Micrometer Head Feed Cross Roller Slide |
| Customized | OEM, drawings or samples customized |
| Travel Range | ±3.2~±25 |
| Specifications | 25 40 60 80 100 120 |
| Platform Dimensions | 25*25 80*80 40*40 60*60 100*100 120*120 |
| Least Count of Micrometer | 10µm |
| Material | Aluminum Alloy |
| Positioning Accuracy Straightness(µm) | 3µm 5µm |
| Unit Weight(kg) | 0.04 0.14 0.25 0.5 0.7 1.6 |
| Load Capacity(kgf) | 1 2 5 10 15 20 |
| Key Features | High Precision Positioning, High Rigidity Design, Flexible Configuration, Excellent Protection, Low Noise Operation |
| Application Industry | Automated Production lines; Vision Inspection; Coordinate Measuring Machines; Laser Cutting, Engraving, Dispensing Equipment; Chip Packaging, PCB Processing |
Application
The product integrates a micrometer head feed mechanism with a crossed roller guide system. It employs two sets of rollers arranged orthogonally on V-groove guideways, which roll and guide synchronously, achieving superior motion accuracy and rigidity. The micrometer feed mechanism enables quantifiable precision adjustment, making it ideal for applications demanding extremely high positioning accuracy. These include precision assembly in 3C electronics, optical instrument inspection, semiconductor alignment, and laboratory measurement equipment.
