iHF Linear Ball Slide for 3C Inspection Equipment
Productfeatures:
The linear ball slide employs a precision-machined double arc groove structure on the main body of the slide. Balls are arranged in an orderly manner within the grooves, and their rolling motion enables high-precision guidance and smooth linear movement.
We currently offer three types of linear ball slides: the micrometer head feed type, the lead screw drive type, and the micrometer feed type. All models are equipped with quantized adjustment function, with a minimum reading value of 0.01mm, making them suitable for precision adjustment applications.
Among these, the lead screw drive type features a Gothic arc groove design, which enables four-point contact between the balls and the raceway at a 45° angle. This structure not significantly enhances rigidity but also achieves micron-level positioning accuracy and extremely smooth, backlash-free movement.
Precision Positioning Stage:
| Product Model | Manual X-Axis Stage |
| Material | Stainless Steel |
| Module | ZD58AN |
| Motion Direction | X-axis |
| Transport Package | Cartons |
| Trademark | iHF |
| HS Code | 9031900090 |
| Feed Type | Micrometer Head Feed |
| Surface Treatment | Electroless Nickel Plating |
| Surface Color | Clear/Natural |
| Application | Precision Electronics, Precision Optics, Laser Processing, Lithium-ion Battery Manufacturing, Optoelectronics |
| Specification | Standard |
| Origin | Dongguan(Mainland) |
| Production Capacity | 100000 PCS/Year |
Product Description:
| Product | Micrometer Head Feed Linear Ball Guide Stage |
| Customized | OEM, drawings or samples customized |
| Travel Range | ±3.2~±12.5 |
| Specifications | 25 40 60 80 100 |
| Platform Dimensions | 25*25 40*40 60*60 80*80 100*100 |
| Least Count of Micrometer | 10µm |
| Material | SUS440C |
| Positioning Accuracy(µm) | 3µm 5µm |
| Unit Weight(kg) | 0.07 0.23 0.4 0.9 1.33 |
| Load Capacity(kgf) | 4 10 20 27 35 |
| Key Features | High Precision Positioning, High Rigidity Design, Flexible Configuration, Excellent Protection, Low Noise Operation |
| Application Industry | Automated Production lines; Vision Inspection; Coordinate Measuring Machines; Laser Cutting, Engraving, Dispensing Equipment; Chip Packaging, PCB Processing |
Application
The X-axis linear ball slide operates by arranging precision steel balls within machined double-arc (Gothic arch) raceways on the slide body. As the slide moves, the balls roll smoothly along these grooves, providing low-friction linear guidance. This design enables fine, quantifiable adjustments—typically with a resolution of 0.01 mm—making it ideal for applications requiring precise positioning, such as optical alignment, precision assembly, laboratory instrumentation, and coordinate measuring equipment.
