Newgear Planetary Gearbox PRF China OEM

Drive the world with planetary transmission and lead the future with precision manufacturing

Product features:

1. Square flange shaft output, a simple grade gearbox with fully customizable input and output design

2. Straight gear transmission, single cantilever structure, extremely cost-effective

3. Durable and reliably efficient

4. The input shaft can be opened with a keyway

5. Return clearance 8-16arcmin

Specification range: 40-160

Speed ratio range: 3-100

Accuracy range: 8-16arcmin

The Newgear Planetary Gearbox PRF combines precision, durability, and flexibility in one compact package. Its planetary gear design ensures high torque transmission, smooth operation, and low backlash, making it suitable for robotics, automation, CNC machinery, and industrial applications. With OEM customization options, manufacturers can adapt the gearbox to meet specific needs while maintaining performance and reliability.

For industries requiring efficient, reliable, and high-performance gear solutions, the Newgear PRF Planetary Gearbox delivers unmatched value and versatility.

Get a free quote

Technical Parameters			Model Series	PRF40	PRF60	PRF80	PRF90	PRF120	PRF160
Maximum Torque			Nm	1.5 Time Rated Torque
Emergency Braking Torque			Nm	2 Time Rated Torque
Maximum Allowable Radial Force			N	185	240	400	450	1240	2250
Maximum Allowable Axial Force			N	150	220	420	430	1000	1500
Torsion Rigidity			Nm/arcmin	0.7	1.8	4.7	4.85	11	35
Maximum Input Speed			rpm	8000	8000	6000	6000	6000	4000
Rated Input Speed			rpm	4500	4000	3500	3500	3500	3000
Noise			dB	≤55	≤58	≤60	≤60	≤65	≤70
Average Life Span			h	20000
Full Load Efficiency			%	L1≥96% L2≥94%
Backlash	P1	L1	arcmin	≤8	≤8	≤8	≤8	≤8	≤8
	P1	L2	arcmin	≤12	≤12	≤12	≤12	≤12	≤12
	P2	L1	arcmin	≤16	≤16	≤16	≤16	≤16	≤16
	P2	L2	arcmin	≤20	≤20	≤20	≤20	≤20	≤20
Moment of Inertia	L1	3	Kg.cm°	0.10	0.46	0.77	1.73	12.78	36.72
		4	Kg.cm2	0.10	0.46	0.77	1.73	12.78	36.72
		5	Kg.cm2	0.10	0.46	0.77	1.73	12.78	36.72
		7	Kg.cm°	0.06	0.41	0.65	1.42	11.38	34.02
		8	Kg.cm2	/	/	0.65	1.42	11.38	34.02
		10	Kg.cm2	0.06	0.41	0.65	1.42	11.38	34.02
	L2	12	Kg.cm2	0.08	0.44	0.72	1.49	12.18	34.24
		15	Kg.cm2	0.08	0.44	0.72	1.49	12.18	34.24
		16	Kg.cm'	0.08	0.44	0.72	1.49	12.18	34.24
		20	Kg.cm2	0.08	0.44	0.72	1.49	12.18	34.24
		25	Kg.cm2	0.08	0.44	0.72	1.49	12.18	34.24
		28	Kg.cm'	0.08	0.44	0.72	1.49	12.18	34.24
		30	Kg.cm2	0.08	0.44	0.72	1.49	12.18	34.24
		35	Kg.cm2	0.08	0.44	0.72	1.49	12.18	34.24
		40	Kg.cm°	0.08	0.44	0.72	1.49	12.18	34.24
		50	Kg.cm2	0.05	0.34	0.58	1.25	11.48	34.02
		70	Kg.cm2	0.05	0.34	0.58	1.25	11.48	34.02
		100	Kg.cm°	0.05	0.34	0.58	1.25	11.48	34.02

Technical Parameters		Model Series	PRF40	PRF60	PRF80	PRF90	PRF120	PRF160
	Specification	Ratio	PRF40	PRF60	PRF80	PRF90	PRF120	PRF160
Rated Torque	L1	3	16	27	50	96	161	364
		4	16	40	90	122	210	423
		5	15	40	90	122	210	423
		7	12	34	48	95	170	358
		8	/	/	35	77	120	300
		10	10	16	22	56	86	210
	L2	12	16	27	50	96	161	364
		15	16	27	50	96	161	364
		16	16	40	90	122	210	423
		20	16	40	90	122	210	423
		25	15	40	90	122	210	423
		28	16	40	90	122	210	423
		30	16	27	50	96	161	364
		35	12	40	90	122	210	423
		40	16	40	90	122	210	423
		50	15	40	90	122	210	423
		70	12	34	48	95	170	358
		100	10	16	22	56	86	210
Degree of protection		IP65
Operating Temperature		—10°C to 90°C
Weight（Kg)	L1		0.43	0.98	2.3	3.12	6.75	15
Weight（Kg)	L2		0.65	1.26	2.97	3.82	9.2	20
